Dished Only Ends
''Heads aren't always the same'': That is a statement, which holds true from several perspectives. Depending an its area of use, there are infinite varieties when it comes to formats, materials, thicknesses or geometrics. This is coupled with the fact that there are many international standards and rules that have to be observed. If you want to be certain of producing a functional and legally irreproachable vessel, than you should decide to work with us.
We have the experience required for vessel heads, cones, hand-hole locks, etc. that reliably meet the respective national provisions. We manufacture our products from materials that we can be hot or cold-pressed in line with market requirements. Weld preparation with numerous different curbs and joggled edges is a matter of course for us. The sizes range from a diameter of 21.3 mm to 3,000 mm with thicknesses of up to 200 mm and more.
| (r1 = 0,8 da bis r1 = 1600 mm) |
| ||||||||
| Hot or cold formed / annealed | |||||||||
Legend
| da | = Outer diameter |
| h3 | = Total height inner |
| r1 | = Dish radius |
| s | = Wall thickness |
ADDITIONAL INFO
We produce all of the standardised head geometries in Europe. We always keep more than 130,000 of these on stock in our warehouse with diameters of 21.3 to 3,000 mm in many sheet metal qualities - to improve our customers' flexibility.
The World's most advanced pressing line
1. Supply disks for hot pressing
2. High-power furnace
3. Supply disks for cold pressing
4. Press (2.700 to) and tool changer
5. Wash- and cooling down system
6. Turning device
7. Stacking
The World's most advanced pressing line
1. Supply disks for hot pressing
2. High-power furnace
3. Supply disks for cold pressing
4. Press (2.700 to) and tool changer
5. Wash- and cooling down system
6. Turning device
7. Stacking
