XE1 docu
The specialist for documented hydraulic bolted joints
- Documentation of the torque in the operating unit
- Fast and safe work due to predefined bolting cases
- Transfer of data to end devices as complete and transparent documentation of bolting operations
- Fully automatic bolting up to the preset hydraulic pressure with only one keystroke
- Automatic shutdown when the final torque is reached, even for multiple bolting operations
- User-friendly remote control with colour display: important operating parameters always in view (motor/oil temperature, operating hours, power consumption)
ADDITIONAL INFO
- Available in performance classes 0.8 to 3.0 l/min at 800 bar
- High bolting speeds with the optional two-stage version: 5.4 to 13.2 l/min at 150 bar
- Available in all voltages and line frequencies
- Single and dual hose operation of your tools
- IP54 protection class – resistant to harsh environmental conditions
- Efficient due to patented motor-under-oil technology
- Durable & sustainable due to pump and valve technology proven in continuous operation
- Robust design – construction site suitable and stable frame construction to protect the unit
- Optimized maintenance intervals guarantee economic efficiency
- Customized due to modular construction system
