ContraFlex® Acoustic Insulation
ContraFlex® acoustic jackets are the solution when acoustic and thermal insulation is required. They withstand the rigours of service duty but are easy to remove and refit when you need to carry out maintenance operations.
Product specifications
Reduce health and safety risk and improve working environment, by insulating key plant and equipment to reduce noise pollution. Our acoustic jackets have been tested in accordance with internationally recognised ISO 15665: and ISO 10140-2:2010.
- First fit velcro type installation
- ISO 10140 transmission loss for up to 52dB (Rw)
- ISO 15665 acoustics for piping, flanges and valves: Class A, B, C and Shell DEP 31.46.00.31
- Specific testing and consultation available for rotating equipment packages (turbines, compressors and pumps)
- Operational range between -55°C and +550°C
- Specific labelling or tagging can be provided for traceability, maintenance, identification and inspection purposes
- As standard, our jackets have a durable outer cloth that is weather and oil resistant.
ADDITIONAL INFO
Compressors and expanders
Our jackets improve compressor overall efficiency and reduce operating costs.
Pipes manifolds and flanges
Fully bonded phenolic coating system, bespoke pre-cast shells and jackets.
Pump thermal and acoustic protection
Using thermal blankets, it is possible to reduce unwanted sound radiation from pump casings. To reduce the sound from a pump casing, the addition of mass is required, or a pre-fabricated enclosure surrounding the equipment isolated from the source.
Turbines
Turbines
Reduce turbine operating costs and improve energy efficiency, fire protection and noise reduction.
